Semi-Automatic Piston Filling Machine for Free Flowing Liquids

Semi-Automatic Piston Filler For Thin Liquid

APACKS entry level tabletop piston filling machine is highly accurate, versatile, and extremely user friendly. This volumetric piston filler draws liquids and other low viscosity products directly from a tank or drum which eliminates the need for a product hopper. This piston filler can also be used as a metering pump to dispense a controlled volume if necessary. Dis-assembly and cleaning is extraordinarily easy and is usually accomplished in a matter of minutes (no tools required). The operator drops a line of flexible tubing into a drum or tank, adjusts the volume of fill to the desired setting and places an empty container under the filling nozzle. With a simple press of a foot pedal, the exact quantity of product is drawn from the drum and dispensed into the container. The machine operates one fill at a time, and stands by until the foot pedal is depressed again.

Spec Sheet Download

Simply click on the link below to open the pdf. If you would like to download it, please right click, and then choose save as.

Download Spec Sheet

  • Tool free strip down for easy cleaning
  • All 316L stainless steel sanitary tri-clamp connections, connection “T’s”, product cylinder, and contact parts
  • Suitable for food and pharmaceutical applications
  • Bottom close positive shutoff nozzles for drip free operations (sized for your application)
  • Small footprint for simple bench mounting
  • Quick release nozzle and feed pipe
  • Pneumatic operation suitable for hazardous areas or wash down facilities
  • Fills free flowing liquids, food products.
  • Drip free bottom close nozzle(s)
  • Filling speeds: Up to 30 b.p.m. (depends on product and container size)
  • Fill accuracy: /- 0.25%
  • Product suction and dispensing speed adjustment
  • Food and pharmaceutical 316 stainless steel contact parts
  • Air requirements: 2-cfm @ 90-psi
  • Any free flowing liquid
  • Replacement parts always in stock
  • Free Phone Support
  • Available with 1 or 2 heads in a variety of piston sizes ranging in volume
  • Food
  • Beverage
  • Chemical
  • Household Products
  • Personal Care
  • Pharmaceutical
  • Biomedical
